AUTO SHOT VALVE ( AUTO GRIT MIXING VALVE ) Characteristics : It closes if + type handle is turned clockwise and vice versa. The handle is made of double screw. Therefore opening and closing are very quick. It opens and closes by rotating handle with the hands. Use : It is assembled to the pipelines on the bottom of the tank of the shot air blasting facility and it controls (open and close) the flow of shot ball. Auto Shot Valve ( Matt Ring Valve ) Use : The structure of this valve is same as that of SGA40A-40A. It is mainly used for small shot tanks. Taps which are assembled to the pipelines on the bottom of the tank and taps on the air line connecting parts are PT 1" (25A) type. There are two sizes (27mm and 38mm) of holes of rubber hose connecting parts on the nozzle side. Auto Shot Valves ( Matt Ring Valve) Use : The Valve is same as the previous auto valve. It is mainly used for small tanks. The taps which are assembled to the bottom of the shot tank and the taps connected to the line are PT 3/4". The hole of rubber hose connecting part on the nozzle side is Ø27mm. Manual shot valves Use : It is same as auto valve and it opens and closes by hands. It closes if + type handle is turned clockwise and vice versa. Manual Shot Valves Characteristics It closes if + type handle is turned clockwise and vice versa. The handle is made of double screw. Therefore opening and closing are very quick. It opens and closes by rotating handle with the hands. Use It is assembled to the pipelines on the bottom of the tank of the shot air blasting facility and it controls (open and close) the flow of shot ball. CONE AUTO MIXING VALVE & AUTO AIR VALVE Auto Air Valves (Cylinder Type) Characteristics : This valve is normally open. Valve pipeline closes when air is supplied to one touch nipple and vice versa. (*Connect this valve to solenoid valve so that there is no air in the valve cylinder.) Valve is normally used at air pressure of 5~9kg/cm2. Be sure of the flow direction indicated on the valve outside when assembling. Use : It is connected to the air line of shot air blasting facility and it controls air flow. SAC40A is applied to pipe 40A pipeline / SAC32A is applied to pipe 32A pipeline Auto Air Valves (Spring Type) Characteristics : This valve is normally closed by spring force. Valve pipeline opens when air is supplied to one touch nipple and vice versa. (If there is air pressure in the cylinder of the valve. air may leak as the pipeline is not completely colsed. Therefore it is necessary to connect solenoid valve to air hose so that air can be completely discharged.) Valve is normally used at air pressure of 5~9kg/cm2. Be sure of the flow direction indicated on the valve outside when assembling. Use : It is connected to the air line of shot air blasting facility and it controls air flow. SAS40A is applied to pipe 40A pipeline / SAS32A is applied to pipe 32A pipeline. Auto Air Valves (Spring Type) Characteristics : The valve is normally colsed by spring force. Valve pipeline opens when air is supplied to one touch nipple and vice versa. (*Connect this valve to solenoid valve so that there is no residual air in the valve cylinder.) Valve is normally used at air pressure of 5~9kg/cm2 . Be sure of the flow direction indicated on the valve outside when assembling. Use : It is attached to the air pipeline of the shot air blasting equipment and controls air flow. Filler Valves Characteristics : This valve is a double acting cylinder type. It opens when air is blown into the upper nipple and it closed when air is blown into the lower nipple. When connecting it to the solenoid valve, be sure that air is completely discharged from the other side when air is blown in one side. Disassemble the upper flanges and weld them to the tank. When making tanks, disassemble the upper flange on the valve and weld them to the top and middle part of the tank and assemble them with bolts. Use : It is assembled to top and middle part of the tank of shot air blasting equipment and it controls the inflow of shot ball to the tank. Pinch Valves Characteristics : This valve is normally open, Valve pipeline closes when air is supplied to the cylinder and vice versa. When connecting solenoid valve to air hose, be sure that the air in the cylinder should be completely discharged. Valve is normally used at air pressure of 5~9kg/cm2. It is possible to change rubber tube by unfastening four bolts and two nuts. It is very convenient compared with the existing valves. Use : It is assembled to the upper part of the tank of the shot air blasting equipment. It discharges the contaminated air form the tank before fill valve opens when shot ball is supplied to the tank. Honing Tools (Hone) Use : It is made of oil stones or sand papers and used for polishing inside of the holes precisely. Specifications Specifications Honing scopes Honing SH-45 (4 blades) Ø45 ~ Ø55 SH-55 (4 blades) Ø55 ~ Ø65 SH-65 (4 blades) Ø65 ~ Ø95 SH-95 (4 blades) Ø95 ~ Ø130 HONING TOOL CONNECTING RODS Tool ins use SH-45, SH-55, SH-65, SH-95 Sagging Tools (Main Engine Bed Level Tool) Characteristics : It is a tool measuring main engine level by applying 40kg of spring tension force to Ø0.5 piano wire during the machine fitting work in the shipyard. Vacuum Breaker (SSVB5060) This will enable you to reduce your time and efforts sharply by more than a half. A Vacuum Breaker, compact and lightweight with little noise during operation. * Characteristics: This is a valve performing the role of adjusting pressure by supplying air from outside to prevent the facility from being distorted in the event of occurrence of vacuum pressure more than need by being assembled to the vacuum recovery facility of the shot-balls scattered in the shot-air-blasting workshop. ※ Depending on the capacity of the facility, it can be widely used by adjusting the double nuts pressing the spring after opening the cover by turning the eye-bolt to counter-clockwise. ※ Especially compared to the existing product of high noise, it has little or no noise during operation. ※ The working pressure is adjustable using the nuts pressing the spring. ※ Flange size of the assembly part (100A x 10K Flange) ※ Exterior Dimensions Φ215mm x Height 470mm ※ Weight: 15kg ※ Patent pending.
